Combined Wi-Fi and Bluetooth module saves space in high-speed RF devices
The Type 2LL from Murata is a dual-band Wi-Fi® 802.11a/b/g/n/ac/ax, Bluetooth® 5.4 and IEEE 802.15.4 wireless module which provides strong security protection for data transmitted over the air.
The Murata Type 2LL is a small wireless module which is based on an NXP Semiconductors IW610G dual-band 2.4GHz and 5GHz chipset.Â
Supplied in a shielded surface-mount package measuring just 7.7mm x 8.8mm x 1.3mm, the Type 2LL facilitates integration into size- and power-sensitive applications such as IoT devices, handheld wireless systems, and gateways.
The Type 2LL module is notable for the strong security protection that it provides to data transmitted over Wi-Fi or Bluetooth networks. The IW610G chipset is supplied with NXP EdgeLockâ„¢ security technology, and is suitable for security-critical equipment which has to meet the requirements of the SESIP Level 3, IEC 62443 or EU RED article 3(3) security standards and regulations.Â
The IW610G chipset implements hardware mechanisms and algorithms for enhanced collaborative coexistence, which ensure that the Wi-Fi, Bluetooth and 802.15.4 radios avoid interfering with each other.
Murata also supplies the similar Type 2KL module: this is based on the NXP IW610F dual-band chipset, which supports Wi-Fi 6 and Bluetooth 5.4 networking.
