High ripple current and capacitance from vibration-proof hybrid capacitor
The EEHZKV121XUV conductive polymer hybrid aluminum electrolytic capacitor from Panasonic Industry combines high ripple current of 1700mA and high capacitance of 120µF in a small case, with 6.3mm diameter and 8mm height.
Offering endurance of 4000 hours at 125°C, the high-temperature capability is added to a long lifetime. Throughout the life of the EEHZKV121XUV hybrid capacitor, the capacitance remains stable, even when operating at high frequency and low temperature.
The low equivalent series resistance (ESR) is achieved by the hybrid capacitor and provides performance which has reduced noise. EEHZKV121XUV delivers a low ESR of just 35mΩ at 100kHz and +20°C, ensuring excellent high‑frequency performance.
In addition to the 35V EEHZKV121XUV capacitor with 120µF capacitance, other vibration-proof hybrid capacitors are the 50V EEHZC1H101V which is rated for 100µF capacitance and the 25V EEHZC1E331V with 330µF capacitance. Panasonic vibration‑proof hybrid capacitors offer up to 1000µF capacitance with vibration resistance of up to 30G, setting a benchmark in the market.
