The STMicroelectronics CAM-55G1 camera modules provide a choice of lens options, all in compact form factors, to accelerate the set-up of low-power embedded vision system prototypes.

The automotive-grade LX34070 from Microchip facilitates compliance with the car industry’s functional safety standards. It provides a smaller, lighter and more robust alternative to traditional magnetic position sensors.

The Infineon OPTIGA™ Authenticate NBT is an NFC Type 4 asymmetric tag with an I2C interface, providing a contactless bridge between an NFC reader such as a smartphone and a host microcontroller.

The NCM3 series power modules from Murata provide a 3 W power output, and are backed by safety certificates with reinforced insulation sufficient for use in mains-powered industrial, medical and energy equipment.

The Vishay SiP32433A/B and SiP32434A/B eFuse switches provide settable limits for over- and under-voltage protection, and block voltage surges and inrush currents over a wide input-voltage range, with either latch off or auto-retry.

Fully integrated RFID reader modules from ELATEC provide the easiest way to implement modern, secure contactless authentication technology in factories and other industrial settings.

The new RZ/A3M microprocessor from Renesas features 128 Mbytes of fast DDR3L DRAM memory for system cost reduction, and supports 1,280 px x 800 px video resolution at a rate of 30 frames/s.

Diodes Incorporated supplies the AH4930, a linear sensor which performs 3D magnetic sensing with temperature compensation in a wide variety of switches, buttons and proximity detectors.

The STMicroelectronics ISM330BX motion sensor combines an accelerometer and gyroscope in a single small package. An internal machine learning processor runs algorithms at the edge, reducing the burden on the host processor.

The Infineon IMSQ120R026M2HH CoolSiC™ MOSFET combines excellent efficiency and tolerance of high-temperature operation, making it ideal for applications such as industrial drives, EV chargers and solar power generation.

The ERA-A series resistors from Panasonic Industry, which can tolerate high temperatures and humidity, are suitable for use in Industry 4.0 signal processing applications which require precise operation and low drift.

The NCS32100 from onsemi operates at speeds up to 60,000 rpm and produces 24-bit position and velocity outputs. The inductive sensing technology helps the NCS32100 to operate reliably in difficult conditions.

The new RACPRO1 series from RECOM, available with rated power outputs up to 960 W, offers excellent thermal characteristics, allowing the power supplies to be densely mounted on the DIN rail.

The STMicroelectronics IIS2DULPX MEMS accelerometer performs free-fall detection, self-orientation and other functions, reducing the need for external components and helping designers to reduce system complexity.

The MicroSpeed connectors from TE Connectivity provide a convenient and reliable way to support applications which implement Ethernet, USB or other high-speed communication protocols.

The MICRO-D backshells from NorComp provide a rugged, shielded option in designs which require tolerance of harsh conditions but which do not require a military specification.

The microBUCK^® and microBRICK^™ families from Vishay are integrated dc-dc regulators which operate over wide input-voltage ranges, and support high output-current requirements up to 40 A.

The ATA6847 from Microchip works with external controller and power devices to provide a complete solution for brushless dc motor system control. The gate driver eval board suits motors drawing up to 35 A current.

The CT4022 and CT4032 from Allegro MicroSystems offer very low-noise performance and high immunity to magnetic interference. Low power consumption makes these sensors ideal for use in clean energy applications.

The ECMF4-40A100N10 from STMicroelectronics provides highly effective noise suppression for high-speed interfaces such as USB Type-C^® ports. The integration of ESD protection helps to save board space and reduce parasitic effects.

The EZ-USB™ FX20 from Infineon is a fully integrated USB peripheral controller which provides a complete solution for USB connectivity in embedded devices. It is backed by a full-featured development kit with software support.

IP67-, IP68- and IP69K-rated SMA extender cables from GCT provide waterproof connections for use in harsh outdoor conditions. The integral sealing offers a more reliable alternative to the application of self-amalgamating tape.

The NPDC series of capacitors from NIC Components provides a wide range of capacitance and tolerance options to give designers the opportunity to match dc filtering characteristics to the needs of the application.

The STGIK10M120T inverter power module from STMicroelectronics provides a thermally efficient and integrated option for industrial motor drives.

The AIROC^™ CYW20829 system-on-chip (SoC) and module from Infineon provide robust Bluetooth^® Low Energy connectivity for industrial and consumer applications, and combine excellent radio performance with low power consumption.

The Hirose KW30 series 100 V connectors feature a robust construction with contacts which offer high mechanical stability. Design features ensure correct mating and minimize the risk of damage to the receptacle when assembled.

The RAIK060 is a complete solution for rotary position measurement in off-axis applications. Resistant to interference and contamination, this encoder is ideal for industrial motor applications and robots.

The new IXD0579M gate driver IC from Littelfuse, which features an integrated bootstrap diode and resistor, helps to simplify high-speed designs for brushless motors, power tools, and dc-dc converters.

The STMicroelectronics CLT03-2Q3 current limiter provides the characteristics required in industrial systems and factory automation equipment, including good noise immunity and low power dissipation.
