The sensor board for the AR2020, a 20 Mpixel CMOS image sensor, produces excellent optical performance in both the visible and near infrared portions of the spectrum. The sensor consumes very little power, making it ideal for use in battery-powered products such as surveillance cameras or video doorbells.

The sensor board can be interfaced to the Demo3 evaluation board, or to an AP1302 evaluation board stacked on the Demo3 evaluation board: in this configuration, it supports a maximum image resolution of 13 Mpixels.

The kit uses the DevSuite software from onsemi for system configuration. The software provides a comprehensive set-up interface, and provides features for evaluating the sensor’s features and capabilities. The sensor board is supplied with a lens.

To get started with the AR2020CSSC13SMTAH3-GEVB, developers also need:

  • Demo 3 evaluation board AGB1N0CS-GEVK
  • Optional AP1302 evaluation board
  • DevSuite software
