Wireless communications

Renesas

The Bluetooth Low Energy Development Kit Pro for the DA14533 SmartBond TINY automotive system-on-chip (SoC) from Renesas includes a motherboard, daughterboard, and cables. It is the ideal platform for evaluating the performance of the small, low-power DA14533 in applications such as tire pressure monitoring and passive keyless entry.

The kit provides users with the following capabilities:

  • Software development
  • Programming the DA14533 via JTAG or UART using the DA1453x software development kit supplied by Renesas
  • RF characterization
  • Hardware prototyping
  • Power measurement
  • 2 x auxiliary voltage/current measurement
  • Monitoring eight digital inputs
  • Connecting MikroBUS™ modules
Infineon

This kit provides a development platform for the Sona™ IF513 module from Ezurio, which is based on the CYW55513 Wi-Fi 6/Bluetooth wireless chipset from Infineon.

Key features:

  • Antenna type: 2 x MHF4L connector for antenna diversity
  • Form factor: pluggable M.2 2230 E-Key
  • Frequencies supported: 2.4 GHz/ 5 GHz /6 GHz
  • Wireless technologies: Wi-Fi 6E, Bluetooth 6.0



Infineon

The EVK-MAYA-W381 from u-blox provides a ready-made application environment for designers working with the MAYA-W381, a module which is based on the CYW55513 Wi-Fi 6/Bluetooth wireless chipset from Infineon. The module provides two external antennas for tri-band Wi-Fi 6/6E and Bluetooth 6.0 connectivity.



Key features of the EVK-MAYA-W381 include:

  • SD card adapters to access the SDIO host interface
  • USB interface to easily access the Bluetooth UART interface via a USB-to-UART bridge
  • Digital and analog audio interfaces for Bluetooth wireless networks
  • SMA connectors for external antennas
  • GPIO pins and other module interfaces accessible through pin headers
  • Multiple power-supply options
STMicroelectronics

The NUCLEO-WB09KE board from STMicroelectronics demonstrates the performance of the STM32WB09, a Bluetooth® Low Energy wireless microcontroller which embeds a powerful and ultra-low-power radio compliant with the Bluetooth® Low Energy SIG specification v5.4.

ARDUINO Uno V3 connectivity support and ST morpho headers allow the easy expansion of the functionality of the STM32 Nucleo open development platform with a wide choice of specialized shields.

Key features include:

  • Ultra-low power wireless STM32WB09KE microcontroller based on the Arm® Cortex®‑M0+ core, featuring 512 kbytes of Flash memory and 64 kbytes of SRAM
  • MB2032 MCU RF board with built‑in PCB antenna
  • Three user LEDs
  • One reset and three user push-buttons
  • Board connectors:
    • USB Type-C®
    • ARDUINO Uno V3 expansion connector
    • ST morpho headers for full access to all STM32 I/Os
  • Flexible power-supply options: USB or external source
  • STLINK-V3EC debugger/programmer with USB re-enumeration capability
  • Comprehensive free software libraries and examples available with the STM32CubeWB0 MCU package
Infineon

The OPTIGA™ Authenticate NBT development kit from Infineon is ideal for the quick and simple evaluation of the OPTIGA Authenticate NBT I2C NFC bridge tag using reference use cases available through GitHub.

The kit simplifies the development of custom applications using a PSOC™ host MCU based on the reference applications. After detaching the adaptor board, the shield may also be used separately for evaluation and application development using other MCU boards.

Infineon

The development kit for the NGC1081 tag-side controller demonstrates the functions of energy harvesting, an NFC interface, a sensing unit, and motor control. The product is based on a 32-bit Arm® Cortex®-M0 processor core operating at a frequency of 28 MHz.
