Integrated 700V GaN flyback converter for high-density power
The STMicroelectronics VIPERGAN100WBTR, is a highly integrated 700V GaN flyback converter delivering 90% efficiency, ultra-low standby power, and up to 100W output for compact, high-density power designs.
High-accuracy battery monitor and protector simplifies multiple cell pack management
The Monolithic Power Systems MP3716 battery monitor and protector integrated circuit (IC) combines precision sensing of voltage, temperature, and current sensing, with independent charge and discharge MOSFET control, to simplify design.
65V linear regulator extends battery life with low quiescent current
The NCP737 series from onsemi are high-voltage linear regulators featuring low quiescent current and a wide input range, ideal for extending operating life in battery-powered industrial and consumer electronics.
Compact power relay carries 110A and adds welding detection for energy switching
In a high-capacity format, the HE-A AHEAxxx power relay family from Panasonic Industry helps high-voltage designers to improve safety and reliability in solar inverters, electric vehicle charging, and industrial power switching.
2,000V MOSFET module supports high efficiency in power designs
An EasyPACK™ power module featuring CoolSiC™ trench MOSFET technology, the FF3MR20W3M1H_H11 from Infineon is providing high current density and low switching losses for rugged energy and industrial systems.
Synchronous step-down converter simplifies power conversion with up to 93% efficiency
The STMicroelectronics DCP3603BCMR synchronous step-down converter combines high efficiency, low quiescent current, and comprehensive protection for battery-powered or industrial mains-powered designs.
High-efficiency bipolar transistors minimize conduction losses in automotive designs
Delivering high conduction efficiency and thermal performance, the DXTN and DXTP 78Q and 80Q series of bipolar transistors, from Diodes Incorporated, enable higher power density in automotive switching and control applications.
1-Form-A solid-state 1500V relay built for high-voltage power solutions
Rated for load currents up to 50mA, the Vishay Intertechnology VORA1150 solid-state relay, provides reinforced isolation and long lifetime for high-voltage power systems, and fast bounce-free switching.
Power module streamlines digital rails with programmable circuit control and sequencing
The Monolithic Power Systems triple-output MPM54313 power module combines three buck rails, integrated inductors, and I2C programmability to simplify multi-rail power, with monitoring, sequencing, and flexible paralleling options.
Efficient PMIC extends primary-cell battery life for embedded IoT designs
The nPM2100 power management IC (PMIC) from Nordic Semiconductor features a toolbox of power-saving functions to maximize battery runtime in primary-cell battery-powered designs.
Automotive-grade MOSFET boosts power density for low-voltage power stages
STMicroelectronics offers its STripFET F8 switch in a surface-mount package which helps automotive designers to reduce conduction losses, limit switching noise, and ease thermal designs.
DIN rail ac-dc power supplies save space in industrial applications
The RACPRO1 series from RECOM is available with rated power outputs up to 960W and offers excellent thermal characteristics, allowing the power supplies to be densely mounted on the DIN rail.
GaN half-bridge transistor boosts power density for compact motor inverter stages
Integrating a 650V gallium nitride (GaN) half-bridge with a high-voltage driver and protections, the STMicroelectronics GANSPIN61x helps designers to build smaller, efficient three-phase motor inverters while keeping voltage slew rate under control.
Split-gate power MOSFETs streamline thermal and switching trade-offs
To boost efficiency and power density in high-current dc-dc rails, the Renesas REXFET-1 power metal oxide MOSFETs combine split-gate switching with compact packages.
Isolated IGBT gate driver delivers 7A peak drive for noisy power stages
Built to simplify robust IGBT and MOSFET gate drives in high slew rate environments, the Littelfuse IX3407B is a single-channel, capacitively isolated gate driver with separate source and sink outputs, and 2500Vrms isolation.
Multi-mode flyback regulator cuts standby power and eliminates audible noise
To enable efficient flyback supplies with no-load power below 30mW for compact home appliance designs, the Monolithic Power Systems HF600-40 integrates a 700V MOSFET and burst mode.
2-in-1 power modules reduce volume in multi-level inverters
The SCZ400x series from ROHM Semiconductor uses a 2-in-1 molded package to deliver high power density and flexible topology options for photovoltaic inverters, uninterruptible power supplies, and more energy systems.
Automotive-grade 650V SiC MOSFET boosts power density in converters
The SCT027HU65G3AG silicon carbide (SiC) power MOSFET from STMicroelectronics supports compact high-voltage converters with fast switching, in addition to robust diode behavior with low thermal resistance.
Galvanic isolated optocoupler provides current transfer ratio up to 600%
Providing low-power signal isolation for battery management and 48V power domains, the Vishay Intertechnology VOMA618A optocoupler offers benefits for automotive and high-reliability industrial systems.
Ruggedized backplane connectors support high-speed data transmission in VPX systems
The MULTIGIG RT series of backplane connectors from TE Connectivity offers modularity and flexibility for high-speed board-to-board interconnects, supporting data rates up to 32Gbits/s in rugged computing environments.
Bidirectional active balancer speeds cell equalization in stacked battery packs
Monolithic Power Systems (MPS) MP2645 is a 5-cell, bidirectional buck-boost active balancer that redistributes charge across series cells with up to 3.75A balance current, using a one-wire stackable interface to scale packs up to 33 series cells.
Reliable connectors offer high current capability for use in industrial equipment
Hirose supplies the DF60 series of connectors in configurations for board or panel mounting. Compatible with 8 to 12 AWG wire, the DF60 connectors offer robust locking for secure connections.
Hybrid capacitors push endurance and ripple current for compact power rails
Panasonic Industry ZC and ZK conductive polymer hybrid aluminum electrolytic capacitors combine low equivalent series resistance (ESR) and strong ripple capability for automotive and industrial power stages.
1,500V SiC MOSFET reduces conduction losses in high-voltage power converters
The S3M0130150K from SMC Diode Solutions offers high blocking voltage and low on-resistance to improve efficiency and to reduce component count in automotive power and renewable energy systems.
